Induction Hardening Case Hardness : > 60 HRc

Induction Hardening Case Depth : 1 - 2 MM

Chill Hardness in Chilled Cast Iron : > 52 HRc

Chill Depth in Chilled Cast Iron : 2 - 4 MM

Surface Roughness : < 0.08 Ra (< 1 Rz)

Surface Flatness : < 0.010 MM (< 10 Microns)

Bore Circularity : < 0.0035 MM (< 3.5 Microns)

Bore Cylindricity : < 0.0035 MM (< 3.5 Microns)

Bore Straightness : < 0.004 MM (< 4 Microns)

Bore Diameter Tolerance : < 0.008 MM (< 8 Microns)

Bore-To-Face Perpendicularity : < 0.025 MM (< 25 Microns)

Parallelity : < 0.010 MM (< 10 Microns)

Positional Tolerance : +/- 0.020 MM (+/- 20 Microns)

Run Out : < 0.003 MM (< 3 Microns)
